Paper vegetable tray making machinery(FC-ZMG6-48)

Ask Lasest Price
Brand Name :	FC
Certification :	CE/ISO9001
Model Number :
Price :
Delivery Time :	Within 40-60 days
Payment Terms :	T/T
Supply Ability :	100set/year

Add to Cart

Product Details
Company Profile

Paper vegetable tray making machinery(FC-ZMG6-48)

Raw material:Waste paper

Output(pcs/hr):350,700,1000,1200,2800-3200,3800-4200,5000-5500

Model:MINI FC-ZMW-1/2/3/4 FC-ZMG3-24/4-32/6-48

Certification:CE, ISO9001

With different mold,Our machine can produce different product,such as egg trays,egg carton,egg box,vegetable trays,fruit trays,can trays,seedling trays,shose trays,alcohol bottle trays,electrical appliances trays etc.

Email: lewis@goodeggtraymahcine.com

Website: www.goodeggtraymachine-com.ecer.com

Skype: lewis15863824208

QQ: 279684828

WeChat: lewis15863824208

Tel:+0086-15863824208

Paper vegetable tray making machinery(FC-ZMG6-48)

It absorbs paper pulp-the raw material, on the surface of mould by vacuum to get various shape and ratio of wet and dry by regulating time. After such working procedure as transferring moulds, releasing moulds to complete paper tray production. Our forming machines adopt advanced PLC programmable controller; selecting of high quality electronic devices and pneumatic components.

Paper vegetable tray making machinery list see below:

1. Pulping system

Pulper, vibration screen, mixer; pulp pump; water pump, control cabinet for pulping system,etc

2. Forming system

Consist of forming platen and transfering platen.

egg tray molds can be mounted on forming platen.

Equiped with vacuum auto draining system; auto cleaning system for the forming mold and auto control cabinet.

3. Drying system

Single layer conveying chain; heated by section;multi burners;

Six layers drying line, energy saving and saving place

The temperature of each section can be adjusted independently;burners with Italian brand;

The energy for option: LPG,GAS,diesel oil,Equiped with auto control cabinet.

4. Stacking system

The finished products will be counted and stacked automatically after drying.

Pls feel free to contact us for more details.

Main Technical Parameters of MINI Pulp Moulding Machine
Product Name:	MINI Egg Tray Machine(Small Cheap and Very Fast)
Model:	MINI FC-ZMW-1	MINI FC-ZMW-2	MINI FC-ZMW-3
Output:	350pcs/hr	700pcs/hr	1000pcs/hr
Molding Mould/pcs:	1	2	3
Transfer Mould/pcs:	1	2	3

Main Technical Parameters of Pulp Moulding Machine
Product name:	Roller type Pulp Moulding Machine(Automatic and high output)
Model:	FC-ZMG3-24	FC-ZMG4-32	FC-ZMG6-48
Output:	2800-3200 pcs/h	3800-4200 pcs/h	5000-5500 pcs/h
Molding Mould/pcs:	24	32	48
Transfer Mould/pcs:	3	4	6

Contact:	Mr Lewis
Email:	lewis@goodeggtraymachine-com.ecer.com
Skype:	lewis15863824208
QQ:	279684828
Wechat:	lewis15863824208
Mobile:	+0086-15863824208
Website:	http://www.goodeggtraymachine-com.ecer.com
We are the professional manufacturer of Pulp moulding Machine and EPE Foam Extruder Line etc in Longkou ,Shandong Province, China.

Main Technical Parameters of MINI Pulp Moulding Machine
Product Name:	MINI Egg Tray Machine(Small Cheap and Very Fast)
Model:	MINI FC-ZMW-1	MINI FC-ZMW-2	MINI FC-ZMW-3
Output:	350pcs/hr	700pcs/hr	1000pcs/hr
Molding Mould/pcs:	1	2	3
Transfer Mould/pcs:	1	2	3

Main Technical Parameters of Pulp Moulding Machine
Product name:	Roller type Pulp Moulding Machine(Automatic and high output)
Model:	FC-ZMG3-24	FC-ZMG4-32	FC-ZMG6-48
Output:	2800-3200 pcs/h	3800-4200 pcs/h	5000-5500 pcs/h
Molding Mould/pcs:	24	32	48
Transfer Mould/pcs:	3	4	6

Contact:	Mr Lewis
Email:	lewis@goodeggtraymachine-com.ecer.com
Skype:	lewis15863824208
QQ:	279684828
Wechat:	lewis15863824208
Mobile:	+0086-15863824208
Website:	http://www.goodeggtraymachine-com.ecer.com
We are the professional manufacturer of Pulp moulding Machine and EPE Foam Extruder Line etc in Longkou ,Shandong Province, China.
